| MOQ: | 500メートル |
| 価格: | 0.1-99 USD/M |
| 標準パッケージ: | 木の鉄のドラム |
| 配達期間: | 10 営業日 |
| 決済方法: | L/C、D ・ D ・ P T/T |
| 供給能力: | 5000 KM/Month |
Single Core 0.6/1KV Low Smoke Halogen Free Mica Tape Power Cable Shanghai Brand
Construction
1 Conductor: Compact stranded copper conductor, Cl.2 as per lEC60228
(11 MicaTape
③lnsulation:XLPE(cross-linked polyethylene) rated at 90°C
(1111 Filler
(5: Wrapping Tape: LSOH BendingTape
⑥Sheath:LSOH,black or other colors,as per lEC60332,60502-1
CodeDesignation
YJ:XLPEinsulation Y: LSOH sheath
Standards
lnternational: IEC60502. IEC60228, (lEC60332-3forFRcableonly) China: GB/T12706,(GB/T18380-3 for FR cable only)
Other standards such as BS, DIN and lCEAupon request
Technical data
Ratedvoltage: 0.6/ 1㎸
Maximum Conductor Temperature: under normal (90°C), emergency(130°C) or short circuit no more than5 s(250°C) conditions Min.AmbientTemp.-15°C,lnstallationTemp.0°C
|
|
